Πρότυπα
IEEE 802.3i 10BASE-T, IEEE 802.3u 100BASE-TX,IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-X, IEEE 802.3x full-duplex flow control,IEEE 802.3af (DTE Power Via MDI).
Πρόσθετα χαρακτηριστικά
Χαρακτηριστικά απόδοσης: Bandwidth 20 Gbps full duplex,Μνήμη buffer: 512 KB ενσωματωμένη μνήμη ανά μονάδα,(MTBF): 157.004 ώρες Ακουστικός θόρυβος: 0 dB,Λιγότερο από 4 μs για 64-byte καρέ.
Signal Rate: 11n: Έως 300Mbps(dynamic),11g: Έως 54Mbps(dynamic),11b: Έως 11Mbps(dynamic).
Ασύρματες Λειτουργίες: Ad-Hoc / Infrastructure mode.
Ασύρματη Ασφάλεια: 64/128 bit WEP, WPA-PSK/WPA2-PSK.
Administrative Switch Management: IEEE 802.1Q Static VLAN (64 groups, Static),Protected Ports,IEEE 802.1p Class of Service (CoS),Port-based QoS,DSCP-based QoS,DiffServ,IEEE802.3ad Link Aggregation (manual or LACP),IEEE 802.1w Rapid Spanning Tree Protocol (RSTP),IEEE 802.1s Multiple Spanning Trees Protocol (RSTP),IEEE 802.1ab Link Layer,Discovery Protocol (LLDP),SNMP v1, v2c, v3 ,RFC 1213 MIB II,RFC 1643 Ethernet Interface MIB,RFC 1493 Bridge MIB RMON group 1, 2, 3, 9,Auto Voice VLAN,DHCP Filtering,Auto denial-of-service (DoS) protection,HTTP and HTTPS,Ping and traceroute,Power saving when link down,RFC 2131 DHCP client,IEEE 802.1x with Guest VLAN,Jumbo frame support ,Port-based security by locked MAC addresses,MAC and Ip-based ACL ,Storm control for broadcast, multicast and unknown unicast packets,IGMP Snooping v1/v2,Port-based egress rate limiting,SNTP Port Mirroring Support (Many to one),Web-based configuration,Configuration Backup/Restore,Password Access Control,RADIUS Support,TACACS+ and RADIUS support,Syslog,Firmware upgradeable,PoE (46 watts of power budget).
Πιστοποίηση: CE mark, FCC Part 15 Class A,VCCI Class A,C-Tick.
