Τοποθέτηση
ATX Form Factor (30.5 cm x 20.8 cm).
Υποστηριζόμενοι Επεξεργαστές
Supports 7th and 6th Generation Intel Core i5/i3/Pentium/Celeron Processors (Socket 1151).
Υποδοχές Μνήμης
Dual Channel DDR4 Memory Technology, 2 x DDR4 DIMM Slots, Supports DDR4 2400 / 2133 non-ECC, un-buffered memory, Supports ECC UDIMM memory modules (operate in non-ECC mode), Max. capacity of system memory: 32GB.
Υποστήριξη Δίσκων
4 x SATA3 6.0 Gb/s Connectors, 1 x M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module.
Εσωτερικές Συνδέσεις
1 x System Panel Header, 1 x TPM Header, 1 x COM Port Header, 1 x Chassis Intrusion and Speaker Header, 1 x CPU Fan Connector (4-pin), 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control), 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 2 x PCIe Power Connectors, 1 x SATA Power Connector, 1 x Front Panel Audio Connector, 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection), 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection), 1 x Power Button, 1 x Reset Button.7.1 CH HD Audio (Realtek ALC897 Audio Codec).Gigabit LAN 10/100/1000 Mb/s, Giga PHY Intel I219V.
Θύρες Επικοινωνίας (Εξωτερικές)
1 x PS/2 Mouse Port, 1 x PS/2 Keyboard Port, 1 x HDMI Port, 4 x USB 2.0 Ports (Supports ESD Protection), 2 x USB 3.2 Gen1 Ports (Supports ESD Protection), 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), HD Audio Jacks: Line in / Front Speaker / Microphone.1 x DisplayPort, 2 x HDMI ports
Συμβατά Λειτουργικά
Microsoft Windows 11 64-bit.
